| Place of Origin | China |
| Brand Name | Guangda |
| Certification | DNV, BV, Rina, ISO, GL, ABS, LR,CCS |
Flexible Pins Transmission Input Shaft Transmission Output Shaft Forging Factory
To guarantee the durability, a fexible pin was designed based on the original straddle-mounted pin for enhanced tooth load sharing and distribution in the planetary gear set (PGS) of a wind turbine gearbox . Flexible pins eliminate the need for straddle mounting, and therefore enable the maximum possible number of planets to be used for any particular epicyclic ratio of power transmission systems. Having more planet gears will significantly increase the input torque density.
Guangda is a specialized in forging research and development, production, sales, service as one of the comprehensive company. We could provide rough blank or semi-finishing or finishing parts focuses on large forging equipment b.We have formed a whole industrial chain of smelting, casting, machining and surface treatment, and our technology and cost control are leading in the world.
Wind turbine forging Description
| Application | Wind power turbine ,wind power gearbox |
| Smelting | EAF+LF+VD |
| Grain size | ≥5 |
| UT | SEP1921,EN10228-3 C/c D/d |
| Heat treatment | Normalized , queching and tempering ,stress relief (if needed )+others |
| Delivery condition | Rough ,Semi-finished ,finished |
| Standard | EN10250,EN10083,SEW550 etc. |
| Equiment | 5000T pressing machine |
| Forging rotio | ≥5 |
Shafts used for other industry
Wind turbine forging Other material we could provide
| Type | Material |
| Carbon steel | C15,C22,C25,C30,C35,C40,C45,C50,C55,C60,S355J2G3 etc. |
| Alloy steel | 25CrMo4,42CrMo(S)4,AISI4130,AISI4140,AISI4150,34CrNiMo6,30CrNiMo8,31CrMoV9, 18CrNiMo7-6,16MnCr(S)5,20MnCr(S)5,51CrV4,20MnCr5,20CrMnMoH etc. |
| Stainless steel | 630 17-4PH,630 17-7PH, 632 15-7MoPH,XM12 15-5PH,2205,2507,F55,2205 etc. |
| Tool and die steel | H11-1.2343,H13-1.2344, 1.2738,1.2718 ,1.2343, 1.2312 ,XPM , 80, DVA etc. |
| Special steel | GH2132, GH3030, GH3128, GH4145 ,GH4169 ,GH4080 ,Inconel600 ,Inconel601 ,Inconel625 ,Inconel718 N07718 / GH4169, Inconlex - 750 ,Incoloy800H,Incoloy825,Incoloy901,Incoloy925,Incoloy926 etc. |
Guangda is a leading and integrated steel manufacturer from smelting, forging,casting, heat treatment to precision smart manufacturing . We could provide rough blank or semi-finishing or precision finishing parts for the wind power industry .
Guangda mainly focus on new energy wind power parts such as large offshore wind turbine castings, wind turbine forgings and wind turbine gearbox parts.60% of our business are for wind power parts . NGC, Flender, Shanghai electric ,CRRC, ZF, Mingyang ,DEC,Windey are all Guangda long cooperation customers in the wind industry.
Based on the powerful overall solution, Guangda uses advanced smelting, forging, heat treatment technology and metal processing technology to connect the upstream and downstream industrial system.
According to the different demands of customers for products, we provide users with integrated product design, processing, assembly and other services, and provide customers with overall solutions and value maximization.
| Wind turbine casting parts | Rotor Hub, Nacelle head carrier , Main carrier, Main shaft ,Shaft sleeve, Torque arm ,Shell frame, Support base , Yaw base plate, Planet carrier ,Cover, Frame, Ring , Tower connection part, Nacelle connection part, All kinds of the structure parts for the widn turbines . |
| Wind turbine forging parts | Main shaft, Flange, Yaw flange ,Rolled Ring, Flanges , Gear box parts etc. |
| Wind turbine gear box parts | Torque arm ,Planet shaft, Sun shaft, Planet gear, Internal gear, Planet carrier, Gear box cover etc. |
| Products type | 2MW 3MW 3.2MW 3.6MW 4MW 4.5MW 5MW 5.5MW 6.25MW 7MW 8MW 8.3MW 11MW 12MW 16.6MW etc |
Guangda manufacture capacity
| Completed supply chain | Guangda is an leading and integrated steel manufacturer from smelting, forging, heat treatment to precision smart manufacturing . |
| Quality control | Guangda achieved completely whole process supply from raw materials to finished products for the wind turbine spindle. |
| Main products | wind power, hydroelectric, thermal, nucler power), milling, oil and gas, shipping equipment, pressure machine, machinery, military, aerospace industries. etc. |
| Annual Capacity |
200000 pcs |
| Customer base | Cooperate with the most of the 10 world top wind turbine manufacturers and other world's leading high-end wind turbine manufacturers to establish a good strategic cooperation. |
| Listed company | Strong scientific research ability , Strength for Market experience and customer service . |
| Certificate | PED,DNV, BV, Rina, ISO, GL, ABS, LR etc. |
