Turbine Forging
>
|
| Place of Origin | Jiangsu China |
| Brand Name | Guangda |
| Certification | DNV, BV, Rina, ISO, GL, ABS, LR ,CCS ,PED |
Sun And Planet Gear Planet Pinion Sun Gear Planetary Forged Gear Blanks
A planetary gear set is made up of three types of gears: a sun gear, planet gears, and a ring gear. The sun gear is located at the center and transmits torque to the planet gears which are typically mounted on a moveable carrier . The planet gears orbit around the sun gear and mesh with an outer ring gear . Planetary gear systems can vary in complexity from very simple to intricate compound systems, depending on the application.
The external gear attached to the central axis of a planetary gear mechanism is called the sun gear. The sun gear, together with the planetary gears, internal gears, and planetary carriers that connect the planetary gears, constitutes the main element of the planetary gear mechanism. When selecting planetary gear mechanisms, the sun gear is used as the input side in the planetary and star type designs, while it is fixed in the solar type design.
Wind turbine forging Specification
| Delivery state | Rough blank, semi-finished blank,finishing gears |
| Material | 18CrNiMo7-6, 30CrNiMo8,17CrNiMo6,20CrMnMo ,4340,34CrNiMo6 42CrMo4,etc. |
| Melting process | EF+LF+VD |
| Delivery state | Rough blank, semi-finished blank,finishing gears,Black, peeled, polishing, bright, sand blast, hair line, etc. |
| Diameter | Max 5000mm |
| Max length/Diameter | 12m |
| Max weight | 60T |
| Annular Capacity | 100000pcs |
| Executive standard | JB/GB/EN/DIN/JIS/ASME/ASTM/ISO |
| Certification | PED,DNV,BV,Rina,ISO,GL,ABS,LR |
| Application | Used for wind turbine gear box ,industril gear box,Generator, transmission, reduction motor, equipment transmission etc. |
Wind turbine forging procedure
Orging process flow quality control: Raw material steel ingot into warehouse(test the chemical content) → Cutting→ Heating(Furnace temperture test) → Heat treatment after forging(Furnace temperture test) Discharge the furnace(blank inspection)→ Machining→ Inspection(UT,MT,Visal diamention, hardness)→ QT→ Inspection(UT, mechanical properties, hardness, grain size)→ Finish machining→ Inspection (dimension)→ Packing and Marking(steel stamp, mark)→ Storage Shipment
High-precision dimensional tolerance;Excellent mechanical properties;Produce different dimension based on customer’s requirements;Advanced manufacture equipments and inspection devices;Excellent technical personality;Control the production procedure strictly;Pay attention on the package protection;Quality full service.
Wind turbine Forgings Manufacture Capacity
| Company type | Science and Technology innovation board listed company. Stock code :688186 |
| Completed supply chain | Guangda is an leading and integrated steel manufacturer from smelting, forging, heat treatment to precision smart manufacturing . |
| Shape | Ring, Shaft, disc, round plate, Dysplasia forgings etc. |
| Smelting | Smelting capacity 500,000.00 ton/year . With own smeliting line of carbon steel,stainless steel, alloy steel and special steel . |
| Annual capacity for the forgings | Forging capacity 300,000.00 ton/year . With own professinal forging press machines 5000ton,4500ton,4000ton,3600ton,2000ton,1000ton and ring rolling mill machines and could manufacture the forging blank ourselves. |
| Machining | Turning, milling, boring ,grinding, finished machining, gear shaping ,gear hobbing, gear grinding capability. |
| Heat treatment | Own professional equipment for heat treatment for Annealing ,Normalizing ,Tempering ,QT, Isothermal annealing,Stress relief , Nitriding , Carburize ,Case-hardening etc |
| Surface treatment | High-pressure cleaning, sand blasting and thermal spraying. Complete surface treatment capability. |
Applications for the sun gear shaft blank
| Rail Vehicles | Oil and gas |
| Mining | Cement |
| Power Generation | Turbo |
| Hydro power | Wind Energy |
| Metallurgy | Sugar |
| Marine and shipbuiding | Machine tools |
| Recycling and processing plants | Rubber and plastics |
