P20 Steel 1.2311 Plastic Mold Tool And Die Steel Forging Finished

P20 Steel 1.2311 Plastic Mold Tool And Die Steel


1.2311 Tool steel is a type die steel which has been pre-hardened by the "super clean" production process, showing a high degree of purity and excellent uniform structure, excellent polishing and light etching engraving.1.2311 is commonly supplied in the hardened and tempered condition with a supply hardness of approximately 300HB.

This steel gives an excellent polished finish and is one of the most widely accepted specifications for machine cut plastic moulds and zinc die casting dies. This grade gives excellent wear resistance but if maximum surface hardness is required for compression moulding plastic dies or similar tools, the steel can be case hardened or nitrided.

1.2311 Plastic Mold Tool And Die Steel Specification




Tool and die steel 1.2311 chemical composition




Tool and die steel 1.2311 Heat treatment



Tool and die steel 1.2311 characteristics

Alloyed and pre-toughened tool steel, especially suitable for polishing and nitriding; high dimensional stability.After heat treatment, machining and polishing performance is good, can be carried out, and can be processed, suitable for chromium surface treatment, material hardness uniform, good toughness, good mechanical processing performance.

A wide range of pre-hardened hardness and good hardness uniformity .The hardness of Guangda 2311 between 28-34 HRC can be adjusted according to customer's requirements, cross hardness fluctuations is ±1.5HRC


Tool and die steel 1.2311 Application


1. Household appliances, TV box cover ,air conditioning shell molds.Large section size plastic mould  thickness up to 1500mm.
2. Car inner decoration die ,such as dashboard die ,sound box die ,etc.
3. Die mounts, zinc die casting molds, liners, supports and injection molds.
4. The versatility of plastic die steel and its high tensile properties allow it to be used in a variety of other applications such as shafts, rails and wear strips.
5. Applied to in zinc, aluminum, magnesium and its alloy die-casting mould ;
6. Hot-pressing mold, all kinds of hot forging die; Metal extrusion die, die set.





About Guangda

Guangda are professional die and tool steel manfuacturer and based on professional technologies,well-furnished equipmnets with rich experience. We provide high quality die steel materials: super large section pre-hardening plastic die , high polishing mirror die , high polishing mirror die , corrosion resistant mirror die , car lamp die steel, high heat strength hot die steel , high heat stability hot work die steel etc .

Products are widely used in automobille,machinery and electronics industry , home appliances ,defense and aerospace industry .Especially , the newly developed die-casting mold steel ,core bar for large diameter steel sleeves and big plastic mould block ,have filled in the technical blanks and reached the top quality in the world .At the same time ,we maintain leading role in advanced vacuum heat treatment technology and advanced surface technology with the support of the research Group .
