Wind Turbine Castings
>
|
| Place of Origin | Jiangsu China |
| Brand Name | Guangda |
| Certification | DNV, BV, Rina, ISO, GL, ABS, LR ,CCS ,PED |
| Model Number | 1.5MW，2MW，3MW，4MW ,5MW, 6MW etc. |
Forgings and Castings Wind Turbine Main Shaft Ductile Cast Iron 0.75-6MW
A wind turbine generates electricity by harnessing the power of wind. A wind turbine shaft is the most central part of a wind turbine, subjected to highly dynamic loads and operating conditions. The energy from wind is converted into mechanical energy with the help of blades and rotors, which is then transferred to a generator through the gear box and shaft.
The wind turbine generally consists of two types of shafts i.e. main shaft and generator shaft. The main shaft is a low speed shaft with the turbine rotor bolted through a strong disc. The generator shaft is a high speed shaft coupled with the output shaft of the gearbox.
Wind power castings mains shaft specification
| Application | Main shaft |
| Steel Grade | Spheroidal cast irons QT350-22AL ,QT400-18AL ,QT500-14, QT500-7, QT600 etc . |
| UT | EN12680-3 |
| MPI | EN1369 |
| Metallic products inspection | EN10204-2004 |
| Surface treatment | Sand blasting ,Corrosion protection and painting |
Advantages for the casting main shaft compared with the forging main shaft
Wind power castings Test
Guangda wind turbine products overview
| Wind turbine casting parts | Rotor Hub, Nacelle head carrier , Main carrier, Main shaft ,Shaft sleeve, Torque arm ,Shell frame, Support base , Yaw base plate, Planet carrier ,Cover, Frame, Ring , Tower connection part, Nacelle connection part, All kinds of the structure parts for the widn turbines . |
| Wind turbine forging parts | Main shaft, Flange, Yaw flange ,Rolled Ring, Flanges , Gear box parts etc. |
| Wind turbine gear box parts | Torque arm ,Planet shaft, Sun shaft, Planet gear, Internal gear, Planet carrier, Gear box cover etc. |
Smelting & Casting & Machining&Surface treatment, one-stop castings delivery capability
| Max length/Diameter | 15m |
| Max weight | 200T |
| Material | QT350-22AL ,QT400-18AL ,QT500-14, QT500-7, QT600 etc . |
| Machining | Turning, milling, boring ,grinding, finished machining, gear shaping ,gear hobbing, gear grinding capability. |
| Heat treatment | Normalizing, QT, annealing, carburizing, nitriding with complete heat treatment capacity |
| Surface treatment | High-pressure cleaning, sand blasting and thermal spraying. Complete surface treatment capability. |
About Guangda
Guangda is a professional manufacturer for the wind turbine parts including the wind turbine castings ,forgings and gear box parts . As we are an integrated steel manufacturer from smelting, forging,casting, heat treatment to precision smart manufacturing .We could provide rough blank or semi-finishing or finishing parts for the wind power industry .
We have deep cooperation with ZF, Mingyang ,DEC,Windey, Envision, NGC,Flender,Shanghai electric ,CRRC. In the field of wind power technology, Guangda manufactures ready-to-install cast parts for wind turbines, according to your specifications and requirements, including heavy-duty and complex components made of a wide variety of materials.
Factory, Custom Wind Turbine OEM/ODM Manufacturing
Wind power components,wind turbine components
wind turbine nacelle head carrier,casting carrier,turbine nacelle head carrier
large head cover,large wind turbine parts,large turbine parts
Spheroidal Graphite Cast Irons
On shore wind power turbine
Off shore wind power turbine
Main shaft in factory
Turbine casting
Shaft casting
iron casting factory
